| Product Model | YSGM051010 |
|---|---|
| 标称调谐频段 | 500～1000MHz@VT=0V～20V |
| Output Power | ≥10dBm |
| 带内平坦度（BW≤200MHz） | ±1dB |
| 供电电压（VCC） | 5V |
| 工作电流 | 18mA |
| 二次谐波抑制 | ≤-5dBc |
| 三次谐波抑制 | ≤-15dBc |
| 特征 | Outer围元器件 射频output阻抗 50Ω |
| 封装尺寸 | 7mm×9mm×2mm 通用Package尺寸 |
| Datasheet Download | Download PDF |
Chip-Easy provides a full range of RF & microwave component selection services, covering passive coaxial devices, active coaxial devices, waveguide devices and more. Our products are widely used in communications, radar, test & measurement, aerospace and other fields.
For technical support or custom services, please contact our sales team:
📞 Phone：0755-83179422 / 13544299442 📧 Email：RFACTIVE@chip-easy.cn / RFPASSIVE@chip-easy.cn / WAVEGUIDE@chip-easy.cn
